The function of an electric wire is to move electrical energy from one location to another. Cables can be designed in a variety of ways, always referencing both local and global rules, depending on their intended use.
Electrical cables Voltage
Electric cables are measured in volts and are classified into one of two groups based on this:
Low voltage cables (up to 750 V).
available in a wide range of applications and with thermoplastic and thermoset coatings. They are designed and built in accordance with internationally recognized standards.
Low voltage cables (up to 1,000 volts): (also known as 0,6/1 kV) This section's cables are used for industrial power installations in a variety of fields (general industry, public installations, infrastructures, etc.). They are built in accordance with international standards (UNE, IEC, BS, UL).
Medium voltage cables range in voltage from 1 kV to 36 kV
They are used to transport electricity from substations to transformer stations.
High-voltage cables start at 36 kV
They are used to transport electricity from one location to another.
Types of wire classified according to their application
Cables for low voltage
Electric panel cables
Wiring electric cabinets using flexible cables. These electrical cables are best suited for interior wiring of electrical cabinets, switch boxes, and small electrical equipment as well as for residential usage, installation in public spaces, and domestic use.
Power cables
Power cables Power cables for commercial and industrial buildings. Power cables are frequently used in industrial settings, for variable frequency drives, and for many kinds of low voltage connections (VFD).
Armored cables
Cables reinforced with aluminum or steel for mechanically aggressive installations. Armored cables are also commonly found in areas where rodents are present, as well as in installations in premises where there is a risk of fire.
Rubber cables
Extra flexible rubber cables have a variety of uses. Rubber cables are used in both stationary industrial facilities and mobile services. Rubber sheath on welding cables is recommended in order to transport high currents between the welding generator and the electrode.
Halogen-free cables
Maximum Security Halogen-free
(LSZH) cables with low smoke and corrosive gas emission in the event of a fire are appropriate for use in wiring of electrical panels and public places, installations of all types in public places, individual derivations, emergency circuits, public distribution networks, and mobile service.
Fire resistant cables
In order to ensure the supply of emergency equipment like signaling, smoke extractors, acoustic alerts, water pumps, etc., these cables are specifically made to convey electrical energy in the harsh conditions that arise during a protracted fire. In areas where public opinion is favorable, their use is advised in emergency circuits.
Control cables
Because they are primarily designed for small home appliances, the connection of manufacturing machine parts, signaling and control systems, the connection of motors or frequency converters, signal transmission where the voltage induced by an external electromagnetic field may affect the transmitted signal, or power supply connections to prevent electromagnetism, control cables for fixed or mobile installations should be extremely flexible.
Instrumentation cables
These are flexible and shielded cables used in industrial installations to transmit signals between equipment. Designed specifically for optimal data transmission in environments with high levels of electromagnetic interference.
Solar wires
These cables are ideal for connecting photovoltaic panels as well as connecting the panels to the DC to AC inverter. They can be installed outside with full guarantees due to the design of their materials and cover, which is especially resistant to solar radiation and extreme temperatures.
Special cables
Electric cables come in a wide variety and can be used for a variety of special installations, including temporary light garland installations at trade shows, connections for overhead cranes, hoists, and lifts, applications in submerged pumps, and lighting, purification, and cleaning systems in swimming pools and other drinking water areas like aquariums and water fountains.
Aluminum cables
Aluminum power wires can be installed permanently indoors, outdoors, or even underground.
Medium Voltage Cable
RHZ1
Halogen-free, XLPE-insulated medium voltage cable, type RHZ1, non-flame and/or non-fire propagation. For the transmission and distribution of electricity in medium voltage networks, they are the ideal cables.
HEPRZ1
Halogen-free, flame- and/or fire-resistant, HEPR insulation, medium voltage cable Perfect for distributing and transporting electricity in medium-voltage networks.
MV-90
American standard medium voltage cable with XLPE insulation. for the movement and distribution of energy in networks with medium voltage.
RHVhMVh
Medium voltage cable made of copper and aluminium for unique applications. especially advised for installations where the presence of hydrocarbon-type chemicals, oils, or their compounds poses a risk.
0.3/0.6kv cables in Turkey
Basic Info:
Uses for this product include hanging cables, drawing cables, installation for field lines, electronic equipment, automatic devices for electric power, chemical, and other uses. It is exceptionally soft, folds and moves effortlessly, is smooth and age-resistant, and is resistant to strong pulse starting current.
property:
1.A.C rated voltage :0.6/1kV
2.long-term operating temp:-40ºC~105ºC for butyronitrile flat cable
3.the min environment
l operating temp:-40ºC fixed installation
4.the laying temp of cable should not be less than 0ºC,it shall be pre-heated if it is less than the min.laying temp.
5.Voltage rating:300/500V,450/750V
6.Flame-retardant Flat Wire and Heat-resistant Flat wire.
7.The product is especially flexible, easily folded and movable, smooth and unbending.
8.Heat, cold, acid and alkali-resistant.
Specification
Standard:HD 21, DIN VDE 0281, BS 6004, BS 6004
For more details, contact us on our website.
